DHO4000 series digital oscilloscope is designed to meet the designing, debugging, and testing requirements of the mainstream oscilloscope market. Adopting the brand-new chipset “Centaurus” developed by scientech, this series achieves a fast waveform capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 500 Mpts memory depth, 12-bit vertical resolution, all combined with excellent noise floor performance and vertical accuracy to meet your requirements for more accurate measurements, bringing extraordinary T&M experience for you

 Features

• Brand-new chipset “Centaurus” developed by scientech
• Ultra-low noise floor at 18 μVrms in minimum
• 12-bit vertical resolution[1]
• 200/400/800 MHz analog bandwidth (selectable), 4 analog channels, and 1 EXT channel
• Up to 4 GSa/s real-time sample rate
• Max. memory depth: 500 Mpts (optional)
• Min. vertical sensitivity: 100 μV/div
• Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
• 10.1” 1280*800 HD touch display
• User-friendly Flex Knobs, bringing smoother interaction
• Standard photoelectric encoder operating knobs, effectively prolonging its service life
• Standard USB Device & Host, LAN, and HDMI interfaces
• Optional battery pack in a highly portable package for unlimited freedom
• Support online version upgrade
