Digital Oscilloscope

DHO1000 Series

DHO1000 series digital oscilloscope is designed to meet the designing, debugging, and testing requirements of the mainstream oscilloscope market. Adopting the brand-new chipset “Centaurus” developed by RIGOL, this series achieves a fast waveform capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 100 Mpts memory depth, 12-bit vertical resolution, all combined with excellent noise floor performance and vertical accuracy to meet your requirements for more accurate measurements, bringing extraordinary T&M experience for you.

Features

Brand-new chipset Centaurus developed by RIGOL
Ultra-low noise floor for cleaner signals, measuring small signals accurately
12-bit vertical resolution[1]
70/100/200 MHz analog bandwidth (selectable), 2/4 analog channels, and 1 EXT channel
Up to 2 GSa/s real-time sample rate
Max. memory depth: 100 Mpts (optional)
Vertical sensitivity range: 500 ?V/div to 10 V/div
Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
10.1” 1280*800 HD touch display
User-friendly Flex Knobs, bringing smoother interaction
Standard photoelectric encoder operating knobs, effectively prolonging its service life
Standard USB Device & Host, LAN, and HDMI interfaces

Model

Model	Bandwidth	Analog Channels	Real-Time Sample Rate	Max. Memory Depth	Waveform Capture Rate	Digital Channels	Quote
DHO1072	70MHz	2	2GSa/s	100Mpts (opt.)	1,500,000 wfms/s	–	–
DHO1074	70MHz	4	2GSa/s	100Mpts (opt.)	1,500,000 wfms/s	–	–
DHO1102	100MHz	2	2GSa/s	100Mpts (opt.)	1,500,000 wfms/s	–	–
DHO1104	100MHz	4	2GSa/s	100Mpts (opt.)	1,500,000 wfms/s	–	–
DHO1202	200MHz	2	2GSa/s	100Mpts (opt.)	1,500,000 wfms/s	–	–
DHO1204	200MHz	4	2GSa/s	100Mpts (opt.)	1,500,000 wfms/s	–	–

Probe

Passive Probe

Model	Description	Manual
RP1018H	18kV 150MHz High voltage probe	DOWNLOAD
RP1300H	300MHz High voltage probe (2kV)	DOWNLOAD
PVP2350	350MHz, 10:1/1:1, passive high resistance probe (single strip)	DOWNLOAD
RP6150A	1.5GHz Passive low resistance probe (500ohm)	DOWNLOAD

Current Probe

Model	Description	Manual
RP1000P	4CH Power Adapter	–
RP1001C	300KHz, 100A DC	DOWNLOAD
RP1002C	1MHz, 70ADC	DOWNLOAD
RP1003C	50MHz, 30A	DOWNLOAD
RP1004C	100MHz, 30A	DOWNLOAD
RP1005C	10MHz, 150A	DOWNLOAD
RP1006C	2MHz, 500A	DOWNLOAD

High Voltage Differential Probe

Model	Description	Manual
PHA2150	200MHz, 1500V High Voltage Differential Probe	–
PHA1150	High voltage differential probe, DC-100MHz, 1500V	DOWNLOAD
PHA0150	High voltage differential probe, DC-70MHz, 1500V	DOWNLOAD
RP1100D	100MHz, 6.5KV	DOWNLOAD
RP1050D	50MHz, 6.5KV	DOWNLOAD
RP1025D	25MHz, 1.4KV	DOWNLOAD
